पीवीसी पाइप थ्रेडिंग मशीन
पीवीसी पाइप थ्रेडिंग मशीन

पीवीसी पाइप थ्रेडिंग मशीन

पीवीसी पाइप थ्रेडिंग मशीन Specification

  • फ़्रेम टाइप
  • Metal Frame
  • फ़्रिक्वेंसी
  • 50/6 Hetrz (Hz)
  • विशेषताएँ
  • Heavy Duty
  • वोल्टेज
  • 220/ 415 Volt(v)
  • मशीन का प्रकार
  • pipe threading machine
  • कूलिंग सिस्टम
  • Air Cooling
  • शोर का स्तर
  • low db
  • उपयोग/अनुप्रयोग
  • Industrial
  • Remote Battery Type
  • AAA
  • Operating System
  • Android
  • USB Ports
  • 2
  • Smart TV Features
  • Built-in WiFi, Screen Mirroring
  • Viewing Angle
  • 178
  • Sleep Timer
  • Yes
  • Refresh Rate
  • 60 Hz



About पीवीसी पाइप थ्रेडिंग मशीन

The PVC Pipe Threading Machines selection we offer is praised by many clients because of durability, precise engineering and optimum output. These machines are employed for cutting the external threads using Tangential chaser that performs as a cutter in the machines. Threads like BSPT, NPT, METRIC, UNC, UNF, BSW, BSP, ACME, BSF Threads, etc., can be cut with these PVC Pipe Threading Machines.

Following major parts form a part of these machines:
  • Base
  • Bed or Pillar Type Clamping Vice
  • Die Head
  • Head Stock
  • Saddle

Rebar Threading Machine, as the very name of the machine implies, is used for threading external area of rebars. This advanced machining system has a threading tool called Rebar Threading Chasers, which work to remove the ribs from TMT bar. The requirement of every manufacturing unit or organization can be different when it comes to Rebar Threading Machine, given to the kind of threading works to be performed. Therefore, we make available Rebar Threading Machine in different models to suit specifics of varied industrial sectors. We have been in the fabrication business for over 10 years and in these years we have never deterred from our quality promise. The product design and development process is carried out by experts to make sure there is no fault in the final product and customers get the complete value for money. Not only machines we sell to our customers, but also complement with excellent after sales services. Every machine that is developed in our production plant is a piece of manufacturing excellence.

PVC Pipe Threading Machine Specifications:

Model1/4 to 1 (Bed Type)3/8 to 1.1/2 (Bed Type)1/2 to 2.1/2 (Pillar Type)(Bed type)
Spindle Speed Range60-9060-9060-90-120
Number of Spindle Speed222 or 3
Threading Capacity1/4 to 13/8 to 1.1/21/2 to 2.1/2
Production per Hour60-8060-8070-90
H.P. Required3 H.P.3 H.P.7.5 H.P.
Lead ScrewProvidedProvidedProvided
Weight (KG) Aprox.500550990



पीवीसी पाइप थ्रेडिंग मशीन
